So far we've seen only motherboards for the processors Intel Skylake in LGA 1151, intended for DDR4 memory module . The memory controller of these processors, meanwhile, support memory type DDR3L .
According to the summary, experts Biostar still do not decide what is the memory support of their board - DDR3 or DDR3L.
This manufacturer is ready to equip some of its motherboards for the processors Intel Skylake with DDR3 and DDR4 slots simultaneously. Of course, the use of a particular memory type can be a rotation, and therefore the possibility of extension limited to a single DIMM connector on each of the two channels.
In the photo we see a traditional connector DIMM memory module of DDR3 type with 240 contacts.
Memory type DDR3L-1600 by SO-DIMM operates at a voltage of 1.35 V and a contact 204. DDR4-2133 Memory type operates at a voltage of 1.2 V and has 288 pins. It must be remembered that the common DDR3 memory is now not only has a higher voltage range, but also different number of pin DDR3L - 240 pieces.
And here is the processor socket LGA 1151, Intel processors generation Skylake. Related Products :
|
