POSTER: computer news   ||   GEFORCE 9600 GT ALTERNATIVE VERSIONS	DATE:2008-02-23
As always, we explain the characteristics and the consumer qualities Of  each announced video card , today we deal with geForce 9600 GT . The most important characteristics, which immediately interested potential owners - is the price , witch is below $200, the 256- bit memory system bus  , the presence of 64 stream processors and the minimum memory volume is equal to  512 mb. Thus, let us transfer the fundamental characteristics of video card geForce 9600 GT standard design: 65 nm chip g94, possesses 225 sq. mm area (against 324 sq. mm in G92); The quantity of transistors : 505 mln. pieces (against 754 mln. pieces in G92); frequency 650/1625/1800 MHz; memory volume 512 mb, memory type - GDDR- 3; 64 stream processors; 32 textural blocks; 16 blocks Rops; energy consumption level  95 W; pureVideo HD new generation technology; PCI express 2.0 support; directX 10 and shader model 4.0 support; support DVI, HDMI DisplayPort at the video chip level  ; recommended cost $169-189. If we consider that G94 is  the half Of g92 only according to the number of stream processors, then this is not entirely correct. Other functional units were not reduced in the same proportion. In particular, the number of textural blocks was reduced from 56 to 32 pieces, and the number of ROPS blocks completely remained as before. Plus the constant 256- bit memory system bus . The chip area is decreased in comparison with G92  by 44% only, and the quantity of transistors is approximately 1.5 time less  . The GeForce 9600 GT confidently competes not only with Radeon HD 3850, but also with Radeon HD 3870, and it even sometimes  approaches the GeForce 8800 GT. . Moreover, the pair Of geForce 9600 GT in SLI regime  exceeds GeForce 8800 GTX. If we look to the recommended prices position, then the GeForce 9600 GT and GeForce 8800 GT are adequately evaluated BY NVIDIA, and here the relationship of energy consumption and performances in GeForce 9600 GT are actually better . In this case the geForce 9600 GT  do not have modest appetite . The technologies of energy-economy are lower then Radeon HD 3850 or Radeon HD 3870, but the speed level  is able to compensate this. Let us talk about the 9600 gt overclocking , standard design video card easily clock to the frequency 750 MHz ( chip ), and 1900 MHz on the shader domain. The memory can be also overclocked to 2200 MHz DDR and even higher. NVIDIA engineers  raised the memory voltage from the recommended 1.9 v  to a value higher than 2.0 v. Now let us examine geForce 9600 GT video card  with alternative design. Galaxy technology company released the original version geForce 9600 GT. Printed-circuit board came out shorter, and cooling system occupies two expansion slot space . Default frequencies are increased to 675/1625/2000 MHz. MSI presented many models Models N9600GT- T 2d1G-OC and N9600GT- T 2d512-OC witch get an identical design, and they are characterized by the memory volume  (1 Gb and 512 mb). Frequencies are equal to 700/1700/1900 MHz. At the same frequencies works the video card MSI N9600GT- T 2d1G-ZILENT with 1 Gb memory and zalman GV1000 cooler . Sparkle released the passively cooled version geForce 9600 GT, which works at frequencies 650/1625/1800 MHz. The alternative version geForce 9600 GT from Palit with sonic suffix is sufficiently uncommon. Users in Europe and Asia will obtain video card with custom cooler . For USA there will be another version with another cooling system, which resembles to gainward solution . Here we have two thermal tubes. Video card in both version operates at 700/1700/2000 MHz frequencies, and in individual cases it can be overclocked up to 800 MHz ( chip ). In usa such card will cost  $215 - this much higher than the recommended $169-189. Asus company  proposes two geForce 9600 GT version, one is equipped with Glaciator cooler . This video card works at regular frequencies 650/1625/1800 MHz, The second work at  720/1800/2000 MHz frequencies. The utility asus smartDoctor allow to independently overclock the shader domain and graphic core. Finally, ECS equips its video card with passive cooler accelero S2, default frequencies are 680/1728/1850 MHz. American stores already propose geForce 9600 GT versions for $179. Related Products :
