ASUS Company released the updated version of motherboard P5N32- E SLI, witch received in its name the prefix plus. Let us recall that P5N32- E SLI, is made on base of chipset NVIDIA nForce 680i, equipped with three PCI express x16, which makes possible to install a pair of graphic adapters in regime SLI and physics calculations accelerator.
The only difference in the new motherboard from the old one is the use of polymeric capacitors. Possible also that the producer improved the FSB stability at frequency 1333 MHz, although the support of this regime remained almost official.
The price of P5N32- E SLI plus is approximately 250 dollars. We think that P5N32- E SLI plus will simply replace its predecessor since in this price segment the chemical capacitors are no longer used.
Technical characteristics:
- Supported processors: Intel core 2 Duo/Quad/extreme, Pentium 4/D/extreme edition
- FSB: 1333/1066/800/533 MHz
- CHIPSET: NVIDIA nForce 680i SLI
- Memory: DDR2 533/667/800 (to 8 Gb), NVIDIA SLI-Ready
- Port Interfaces: 6 x SATA II (RAID 0, 1, 0+1, 5, JBOD), 1 x IDE (2 devices)
- Expansion cards: 3 x PCI express x16, 1 x PCI express x1, 2 x PCI
- Audio (separate module supremeFX): 7.1- channel HD- codec ADI 1988B
- Network: 2 x gigabit ethernet (Marvell 88E1116)
- Ports: 2 x IEEE1394 (VIA VT6308P), 10 x USB 2.0
- 8 phase power diagram, cooling system with thermal tubes stack cool 2
- Form factor: ATX
