Associate reported the characteristics of GeForce GTX 980 MSI Ti Series Lightning card. The rated frequency do not exceed 1203/1303/7096 MHz.
On the reverse side of the printed circuit board is also provided reinforcing plate with logo Lightning.
The PCB design uses elements of defense class.
The power system is based on a 12 + 3 + 1 phase to the power supply card is connected via two Eight-six-pin connectors and one.
On the printed circuit board pads are provided for measuring voltages with a multimeter.
A special tool allows to control the fan speed and change other settings. Related Products :
|
