AMD is preparing an updated platform Sabine, which will appear this year and will include several new mobile processors Llano models. List of new processors are follows:
A common feature of all the new models will be an indicator of heat, equal to 45 watts, which contradicts earlier information on the chip A4-3320M, A6-3420M and A6-3520M. The document also refers to the 4 MB second level cache with A4-3300M and A4-3305M, which is also true for A4-3300M (and, apparently, for A4-3305M, too).
The slowest new products will be A4-3305M with a clock frequency of 1.9 GHz @2.5 Turbo Core. The chip has no obvious differences from the model A4-3300M, but it is possible that the processor will receive a larger L2 cache or better graphical component.
Six other processors will come to replace the six models of the first wave mobile Llano. Thus, the model A4-3320M and A4-3330MX will replace A4-3300M processors and A4-3310MX, they will have two cores and 2 MB second level cache. A6-3400M and A6-3410MX APU will be replaced by A6-3420M and A6-3430MX, and the place of A8-3500M and A8-3530MX processor will take A8-3520M and A8-3550MX.
Model |
Number of Cores |
Frequency @ Turbo Core |
L2 cache |
TDP |
A4-3305M |
2 |
1.9 GHz @2.5 |
2 MB |
45 watts |
A4-3320M |
2 |
2.0 GHz @2.6 |
2 MB |
45 watts |
A4-3330MX |
2 |
2.4 GHz @2.6 |
2 MB |
45 watts |
A6-3420M |
4 |
1.5 GHz @2.4 |
4 MB |
45 watts |
A6-3430MX |
4 |
1.7 GHz @2.4 |
4 MB |
45 watts |
A8-3520M |
4 |
1.6 GHz @2.5 |
4 MB |
45 watts |
A8-3550MX |
4 |
2.0 GHz @2.7 |
4 MB |
45 watts |
