POSTER: computer news   ||   THREE EVGA MOTHERBOARDS DESIGNED FOR SKYLAKE ENTHUSIASTS	DATE:2015-08-06
Yesterday's debut processors Skylake-K motherboard manufacturers have been looking forward for months.    By itself, the platform  Intel Z170 offers no radical innovations. EVGA company is well aware that the interest of enthusiasts need to be heated due to the motherboard with an unusual combination of features.  For example, the model Z170 Classified 4-Way is aimed at lovers of configurations for multiple graphics cards.  Standard 40 PCI Express lanes, it divides among the four connectors PCI Express x16 and one PCI Express x4.  When you install multiple graphics cards using one of the schemes: "1x16", "2x16", "3x8" or "4x8".   Four DIMM slots capable of working with memory type DDR4-3200 total volume of up to 64 GB.  Audio system Creative Sound Core3D Quad-Core with optical output.  The rear panel provides six ports USB 3.0, two USB 2.0 ports and two USB 3.1.  Built-in video output can be operated via the DisplayPort 1.2 and HDMI 1.4.  To connect the drives used eight SATA-600 ports and two slots M.2 (Key M / E) with baud rates up to 32 Gbit / s.  This motherboard is made in the form factor of the E-ATX (263,5 x 304,8 mm).  Removable BIOS chip facilitates  motherboard resuscitation.  For overclockers board includes not only buttons, but also indicators of code  and temperature indicator.  Processor socket with a high content of gold also emphasizes the focus on improved operational stability during extreme overclocking.   On the processor socket contacts for motherboard EVGA Z170 FTW gold a little less, but still a half times more than usual.  The design is made of six-layer board layout in the form factor ATX (243,8 x 304,8 mm), power system limited to 5 phases.  The number of PCI Express lanes limited to twenty, so the scheme with a maximum load is determined by a combination of "x8 + x8 + x4 + x1".  In addition to the four slots PCI Express x16, one slot is provided PCI Express x4.  Number of USB 3.0 ports on the rear panel is six, there are two ports USB 2.0, and no USB 3.1.  The drives connect either to the six SATA-600 ports, or to a single port M.2 (Key M).  Instead of the two network ports in the previous board, this is equipped with only one.  Both boards are equipped with a proprietary SLI-bridge to connect  two graphics cards. Compact solution is the motherboard EVGA Z170 Stinger format mini-ITX (170 x 170 mm), which retained the 10-layer design and 4-phase power system, as well as increased and a half times the gold content in the coating contacts the CPU socket LGA 1151. Onboard buttons temperature indicator and code , removable chip BIOS -  all still there.  But with the expansion slots are  provided only PCI Express x16, and the memory can be installed in only two DIMM slots for modules such as DDR4-3200 +.  Also there are  four ports SATA-600 and one M.2 (Key E), Gigabit Ethernet port, six USB 3.0 ports and two USB 2.0.  All three boards are on the reverse side under the processor socket get reinforcing plate Nickel CPU ILM, content with the last two sound solution Realtek HD Audio with optical output.   Related Products :
