After upgrading the desktop video cards range with the GEFORCE GTX 680, NVIDIA has announced a line of mobile graphics cards GeForce 600M. Usint the architecture Kepler, designed for laptops, we are familiar with the example of Acer laptop .
The GeForce 600M graphics processor with a new architecture - GK107, produced on 28 nm technology, 384 core CUDA, 16 blocks ROP, 64 texture units and has 128-bit bus to access memory. Like its close relative, GK104 , the GPU has the support of API DirectX 11.1, the smoothing algorithm TXAA, the mechanism of dynamic overclocking GPU Boost. In addition, GK107 supports useful for mobile computing technology NVIDIA Optimus.
Formally, the presented line of accelerators can be divided into three classes. Enthusiasts:
|
GeForce GTX 675M |
GeForce GTX 670M |
GeForce GTX 660M |
| GPU (production rate) |
GF114 (40 nm) |
GF114 (40 nm) |
GK107 (28 nm) |
| Core CUDA |
384 |
336 |
to 384 |
| The GPU frequency |
620 MHz |
589 MHz |
835 MHz |
| Shader Clock |
1240 MHz |
1196 MHz |
- |
| Memory Clock (QDR) |
3000 MHz |
3000 MHz |
4000 MHz |
| Memory Bus |
256-bit |
192-bit |
128-bit |
| Memory bandwidth |
96 GB / s |
72 GB / s |
64 GB / s |
| The amount of memory |
up to 2 GB GDDR5 |
up to 2 GB GDDR5 |
up to 2 GB GDDR5 |
High performance mid-level graphics cards:
|
GeForce GT 650M |
GeForce GT 640M |
GeForce GT 640M LE |
| GPU (production rate) |
GK107 (28 nm) |
GK107 (28 nm) |
GK107 (28 nm) |
GF108 (40 nm) |
| Core CUDA |
to 384 |
to 384 |
to 384 |
96 |
| The GPU frequency |
850 MHz |
625 MHz |
500 MHz |
762 MHz |
| Shader Clock |
- |
- |
- |
1524 MHz |
| Memory Bus |
128-bit |
128-bit |
128-bit |
128-bit |
| Memory bandwidth |
64 GB / s |
64 GB / s |
28.8 GB / s |
50.2 GB / s |
| The amount of memory |
up to 2 GB |
up to 2 GB |
up to 2 GB DDR3 |
up to 2 GB |
Finally, this entry-level graphics, which uses 28 nm process GPU architecture Fermi:
|
GeForce GT 635M |
GeForce GT 630M |
GeForce GT 620M |
| GPU (production rate) |
GF116 (40 nm) |
GF108 (40/28 nm) |
GF108 (28 nm) |
| Core CUDA |
114 |
96 |
96 |
| The GPU frequency |
675 MHz |
800 MHz |
625 MHz |
| Shader Clock |
1350 MHz |
1600 MHz |
1250 MHz |
| Memory Bus |
192-bit |
128-bit |
128-bit |
| The amount of memory |
up to 2 GB GDDR5 |
up to 2 GB DDR3 |
up to 1 GB DDR3 | Related Products :
|
