Asus has introduced a compact motherboard with a pre-processor VivoMini UN66, which, according to developers, is the first compact motherboard size of 4 by 4 inches (101.6 x 101.6 mm).
VivoMini UN66, depending on the model, can be equipped with a processor Intel Core i3-6100U, Core i5-6200U and Core i7-6500U, each of which has a built-in Intel HD Graphics 520. Novelty is equipped with a pair of graphics SO-DIMM slots for RAM modules DDR4-2133 memory, the total volume of up to 32 GB. To connect the storage device has one port and one SATA 3.0 connector M.2. The board has one more M.2 connector for connecting the wireless module Wi-Fi and Bluetooth.
Novelty is equipped with Gigabit LAN controller, pin connector for the serial port, IR sensor for the remote control, as well as two ports for interfacing with sensors and other embedded devices capable of receiving these types of signals such as GPIO, SMBus, I2C and DMIC. Set external connectors board VivoMini UN66 includes HDMI and VGA video outputs, four ports USB 3.0, 3,5-mm audio jack and a network port. Related Products :
|
